Oxazolidine

An oxazolidine is a five-membered ring compound consisting of three carbons, a nitrogen, and an oxygen. The oxygen and NH are the 1 and 3 positions, respectively. In oxazolidine derivatives, there is always a carbon between the oxygen and the nitrogen (or it would be an isoxazolidine).[1][2] All of the carbons in oxazolidines are reduced (compare to oxazole and oxazoline). Some of their derivatives, the oxazolidinediones, are used as anticonvulsants.

Oxazolidine
Names
Preferred IUPAC name
1,3-Oxazolidine
Other names
Oxazolidine
Identifiers
3D model (JSmol)
ChEBI
ChemSpider
ECHA InfoCard 100.127.875
MeSH C064210
UNII
Properties
C3H7NO
Molar mass 73.0938 g/mol
Except where otherwise noted, data are given for materials in their standard state (at 25 °C [77 °F], 100 kPa).
N verify (what is YN ?)
Infobox references

Oxazolidines were first synthesized over 100 years ago.[3]

Monooxazolidines

Oxazolidines that are the precursor to bisoxazolidines are in effect mono-oxazolidines. They are also used as moisture scavengers in Polyurethane and other systems. [4] [5]

Dioxooxazolidines

Oxazolidines where the carbon centers at the 1 and 3 positions are carbonyls are called dioxooxazolidines. Some of these are commercial fungicides including chlozolinate, vinclozolin, and famoxadone.[6]

Bisoxazolidines

Bisoxazolidines are chemical compounds that contain two oxazolidine rings, they are used as performance modifiers in polyurethane coatings and paints. The rings hydrolyze in the presence of moisture to give amine and hydroxyl groups, these can then react with diisocyanates, polyisocyanates and polyurethane prepolymers to form a coating.[7] The use of a bisoxazolidine in a polyurethane systems can prevent the unwanted reaction between isocyanate and moisture resulting in coating defects, as a result of carbon dioxide release. This moisture triggered curing route is preferential to moisture cure. As the ring opening reaction is catalyzed by acids, usually organic acids or anhydrides of carboxylic acids are added in a small amount.

The choice of linker between the two oxazolidine rings has a large impact on the performance when used to cure isocyanates. A rigid linker group increases a polyurethanes toughness. A flexible linker group imparts flexibility and increases elongation of a coating. These differences are the reason why bisoxazolidines are used to enhance the performance of polyurethane systems. Usually the rings are linked by esters, urethanes, carbonate or have the two rings fused together. A key intermediate in manufacturing bisoxazolidines is 2-[2-(propan-2-yl)-1,3-oxazolidin-3-yl]ethanol. The hydroxy group on the molecule allows for further reaction with hexamethylene diisocyanate for example.[8][9]

Isoxazolidines

In an isoxazolidine nitrogen and oxygen occupy are adjacent (positions 1 and 2 in the ring ), this is the saturated analogue of Isoxazole.

isoxazolidine

Isoxazolidines can be produced by the nitrone-olefin (3+2) cycloaddition reaction.

500pxg
